Additional Features:

• Voltage: 60V
• Current: 3.2A
• Power: 192W
• Monitor load currents from 100nA to 6A with high accuracy
• Measure voltage and current with 6½-digit resolution
• Capture dynamic load currents as short as 140μs
• Output up to 192W of low noise, linear regulated power
• Programmable rise and fall times eliminate voltage overshoot and undershoot transients
• Built-in graphing simplifies analyzing trends or displaying voltage or current waveforms
• High resolution TFT display and soft-key/icon-based user interface simplify power supply operation
• Programmable output sequences reduce test times
• Sink up to 0.45A to discharge voltage quickly
• Digital I/O for direct communication with other devices and instruments
• GPIB, USB, and LAN interfaces
• Built-in web page simplifies automated control/monitoring
• Automate tests easily with KickStart start-up software
• 3 Year Warranty

Included Accessories:

• Quick Start Guide
• KickStart Quick Start Guide
• User Documentation CD
• LAN Crossover Cable
• Power Cord
• Rear Panel Mating
• Connector with Cover

The Keithley 2280S-60-3 Precision Measurement, Low Noise, Programmable DC Power Supplies are much more than just sources of clean power; they are also precision measurement instruments. They can source stable, low noise voltages as well as monitor load currents over a wide dynamic range from amps to nanoamps. The 2280S-60-3 can output up to 60V at up to 3.2A.

The Keithley 2280S-60-3 supply delivers up to 192W of low output noise power and superior load current measurement sensitivity. Built-in plotting functions allow monitoring trends such as drift. These supplies offer up to 6½-digit resolution for characterizing small changes in load currents with confidence. Four load current measurement ranges support measuring a device’s full load current, standby mode current, and small sleep mode currents with DMM-quality accuracy.

Both supplies use linear regulation to ensure low output noise and superior load current measurement sensitivity. A high resolution color Thin Film Transistor (TFT) screen displays a wide range of information on measurements. Soft-key buttons and a navigation wheel combine with the TFT display to provide an easy-to-navigate user interface that speeds instrument setup and operation.
