Product Details
＋
| Product Attribute | Attribute Value |
|---|---|
| Alternate Mfr Part Number | 66660 |
| Body Style | Puck |
| Connection Type | QD Pigtail |
| Diameter, Body | 8 |
| Housing Material | Thermoplastic |
| Humidity | 90% @ 50 C |
| Indicator | LEDs |
| Input Output | Discrete |
| IP Rating | IP67 |
| Light Source | Visible Red LED |
| Material, Lens | Acrylic |
| Maximum Operating Temperature | 55 C |
| Measurement Range | 0.05 m |
| Mechanical Angle | 1 On, 0.5 Off |
| Minimum Operating Temperature | -20 C |
| Mounting Type | M8 Threaded |
| NEMA Rating | NEMA 6 |
| Number of Pins | 3 |
| Operating Temperature, Maximum | 55 C |
| Operating Temperature, Minimum | -20 C |
| Operation | Light-ON |
| Output | PNP |
| Response Time | 1,0.5 ms |
| Sensing Mode | Diffuse |
| Sensing Range | 50 |
| Series | |
| Supply Voltage | 10-30 VDC |
| Time, Turn-On Delay | 150 ms |
| Type | Reflective Sensors |
